As organizations increasingly move toward infrastructure-as-code, securing cloud resources with fine-grained access becomes essential. In this article, we’ll explore how to secure an Elastic Cloud deployment using Terraform by managing Role-Based Access Control (RBAC) and API keys, which are all fully automated.

We’ll provision:

• An Elastic Cloud deployment with Kibana and Enterprise Search.
• A secure API key with fine-grained access using a custom role.
• Terraform-managed configuration with clean and reusable code.

Why This Matters

While spinning up an Elastic Cloud deployment is straightforward, securing access and managing roles consistently across environments can be tricky. Terraform allows us to version-control and automate security configs, making deployments both reproducible and secure.

Project Structure

Project Structure looks like:

.
├── main.tf
├── state.tf
├── provider.tf
├── variables.tf
└── terraform.tfvars

1. Provider Setup

In provider.tf, we define both the Elastic Cloud and Elastic Stack providers. This connects Terraform to the right APIs.

terraform {
  required_providers {
    ec = {
      source  = "elastic/ec"
      version = "~> 0.12.2"
    }
    elasticstack = {
      source  = "elastic/elasticstack"
      version = "~> 0.11.4"
    }
  }
}

provider "ec" {
  apikey = var.elastic_api_key
}

provider "elasticstack" {
  elasticsearch {
    username  = "elastic"
    password  = var.elasticsearch_password
    endpoints = [ec_deployment.elasticsearch.elasticsearch.https_endpoint]
  }
}

2. Provision Elastic Cloud Deployment

We define the deployment in state.tf. It includes an Elasticsearch cluster with a hot tier, Kibana, and Enterprise Search.

resource "ec_deployment" "elasticsearch" {
  name                   = "rahulranjan"
  region                 = "gcp-us-central1"
  version                = "8.17.3"
  deployment_template_id = "gcp-storage-optimized"

  elasticsearch = {
    hot = {
      size        = "4g"
      zone_count  = 2
      autoscaling = {}
    }
  }

kibana = {
    size       = "1g"
    zone_count = 1
  }

  enterprise_search = {
    size       = "2g"
    zone_count = 1
  }
}

3. Secure Access with API Key

In main.tfWe generate an API key using a custom role with full cluster and index operations access.

resource "elasticstack_elasticsearch_security_api_key" "api_key" {
  depends_on = [ec_deployment.elasticsearch]
  name       = "terraform-api-key"

  role_descriptors = jsonencode({
    "custom-role" = {
      cluster = ["all"]
      index = [{
        names      = ["*"]
        privileges = ["all"]
      }]
    }
  })
}

This ensures we can securely authenticate without using the elastic Superuser credentials in the long term.

4. Secure Variables

In variables.tfWe declare sensitive variables for storing credentials:

variable "elastic_api_key" {
  description = "API key for Elastic Cloud"
  type        = string
  sensitive   = true
}

variable "elasticsearch_password" {
  description = "Password for the elastic user"
  type        = string
  sensitive   = true
}

These values are passed through terraform.tfvars:

elastic_api_key        = "your-ec-api-key-here"
elasticsearch_password = "your-elastic-password-here"

 Don't commit terraform.tfvars to version control.

To apply your secure configuration:

terraform init
terraform plan
terraform apply

Once applied, Terraform provisions your Elastic Cloud deployment and generates a secure API key with scoped access.

Optional Enhancements

You can extend this setup with:

• Monitoring roles for observability use cases.
• Audit logging configurations.
• Dashboards or alert rules created via Elastic’s Saved Objects API.
• Outputting secrets to Vault or Secrets Manager.

Conclusion

Using Terraform to manage RBAC and API keys in Elastic Cloud offers massive benefits in automation, repeatability, and security. You eliminate manual errors, ensure consistent roles across environments, and streamline developer onboarding.

The project code is available on my GitHub.
